測量原理：電化學傳感器

 測量范圍：0.00~2.00%/0.00~4.00%/0.00~25.00%

精       度：±1%FS

重  復 性 ： ± 1 %FS

穩  定  性：±0 .5%FS/7d

響應時間：t90≤10秒

  觸點容量：120VAC,1A      24VDC,1A

輸出信號：4~20mA  電流輸出

 工作電源：24VDC

外形尺寸：200mm  (長)×180mm  (寬)×90mm  ( 高 ) , 可 定 制

防爆標志：ExdIⅡICT6

 重      量：1.0kg

使用壽命：>6年(規范操作正常使用條件下)

氣路接口：φ6 不銹鋼管(可根據客戶訂制)

安裝方式：嵌入或壁掛式安裝

●進口電化學傳感器，具有壽命長、精度高、響應快等特點；

●體積小、重量輕，便于安裝；

●分體防爆設計；

●一次表帶現場顯示功能；



●  上下限控制點可在全量程范圍內任意設置；

●報警點可在全量程范圍內任意設置。

電解水制氫、石油化工、空分、醫藥行業以及生物發酵等工業生產過程中氧含量的本安防爆 的在線檢測分析。
